CCS希希爱视 LDF-200X20RGB-NB 外观缺陷检测用光源
发光颜色 | RGB |
---|---|
峰值发光波长 | Red: 658 nm typ. Green: 520 nm typ. Blue: 450 nm typ. |
外观尺寸 | W 216 mm x D 63 mm x H 49 mm |
输入电压 | 24 VDC |
消耗功率 | 12.0 W max. (Red: 3.744 W, Green: 6.096 W, Blue: 2.16 W) |
极性, 信号 | 1: (+), 2: NC, 3: (-) |
线缆长度 | 300 mm |
外壳材质 | Aluminum alloy |
输入端口 | SMR-03V-B |
适合规格 | [Compatible standards] CE, UKCA EN60825-1, BS EN60825-1, GB7427.1, IEC60825-1, IEC62471 Laser Classifiaction:Class 1 Photobiological Safety Evaluations : Exempt [Environmental regulations] RoHS |
使用温湿度 | Temperature: 0 to 35°C, Humidity: 20 to 80%RH (with no condensation) |
保存温湿度 | Temperature: -20 to 60°C, Humidity: 20 to 80%RH (with no condensation) |
冷却方式 | Natural air cooling |
重量 | 1.1 kg max. |
注意事项 | The warranty period is for half a year from when the product ships. Emission amounts not guaranteed. |
